MG series vacuum switches are housed in pressed steel powder coated enclosure and are recommended for panel mounting or intdoor service. The repeat accuracy is better than ± 1.5% FSR. A 3/8” cable entry is provided for cables and a terminal strip suitable for wired ends is provided inside the enclosure. Pressure port is 1/4” BSPF standard.


  • Grinding Machines For Holding Jobs
  • Vacuum Systems
  • Blowers
  • Pumps

Product Features

  • Compact
  • Separate chamber for working parts
  • Choice of wetted parts to suit working media
  • Electrical rating : 5A, 250VAC; 0.2A, 250 VDC
  • Pressure port : 1/4” BSPF
