Information

CS 12 compressor pressure switch offers peace of mind and unbeatable features. This switch avaible in ready to use condition. Special unloader valve prevents compressors from starting under load. No special mounting required for this switch.

Applications

  • Compressors

Specification

  • Sensing Element : Nitrile Rubber.
  • Factory setting  : 6~ 8 bar.
  • Input Pressure Port  :1/2" BSP Female
  • Relief valve : 6 mm dia.
  • Cable Leading :  11.5 & 14.5 mm diameter.
  • Electrical Rating : 16 A, 500 V AC
  • Protection : IP 44.

Product Features

  • Ready to use,Easy to fit
  • No Special Mounting
  • Non metallic cover
  • Manual cut off
  • Available in ready to use condition

Get Quote
